MikroTik RouterOS RB450G- Akcija

Ispravan i testiran, ide sa originalnim napajanjem. . . The RB450G is a five port Gigabit ethernet router. Comparing to the RB450, the RB450G not only adds Gigabit speed capability, but also 256Mb of RAM, a faster CPU and a microSD card slot for file storage.

The device is powered by a fast AR7161 680MHz Atheros CPU, and also includes a temperature sensor and voltage monitor.

RB450G includes RouterOS - the operating system, which will turn this powerful system into a highly sophisticated router, firewall or bandwidth manager. Specifications

Details

Product code RB450G

Architecture MIPSBE

CPU AR7161

CPU core count 1

CPU nominal frequency 680 MHz

License level 5

Operating System RouterOS

Size of RAM 256 MB

Storage size 512 MB

Storage type NAND

Tested ambient temperature -20°C . . +70°C tested

Powering

Details

PoE in Passive PoE

PoE in input Voltage 8-28 V

Number of DC inputs 2 (DC jack, PoE-IN)

DC jack input Voltage 8-28 V

Ethernet

Details

10/100/1000 Ethernet ports 5

Peripherals

Details

Memory card type microSD

Memory Cards 1

Serial port RS232

Other

Details

PCB temperature monitor Yes

Voltage Monitor Yes

-

Ethernet test results

RB450G AR7161 1G all port test

Mode Configuration 1518 byte 512 byte 64 byte

kpps Mbps kpps Mbps kpps Mbps

Bridging none 58.0 704.4 171.9 704.1 187.3 95.9

Bridging 25 bridge filter rules 58.5 710.4 84.5 346.1 86.4 44.2

Routing none 59.7 725.0 136.1 557.5 147.0 75.3

Routing 25 simple queues 55.2 670.3 117.7 482.1 137.0 70.1

Routing 25 ip filter rules 54.7 664.3 59.4 243.3 59.2 30.3

All tests are done with Xena Networks specialized test equipment (XenaBay), and done according to RFC2544 (Xena2544)

Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes

Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out

Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results. POGLEDAJTE I OSTALE MOJE OGLASE
